EricaSynths Fusion VCA / Waveshaper / Ringmodulator

EricaSynths

EricaSynths Fusion VCA / Waveshaper / Ringmodulator

EricaSynths Fusion VCA / Waveshaper / Ringmodulator

$549.00

$559.00

The Fusion VCA/Waveshaper/Ringmodulator is a complex sound processor that combines VCA, waveshaper and ringmodulator. It’s not a regular VCA; it can operate as one, but most of the power of the module is in advanced modulations – with two CVs applied simultaneously to different stages of the VCA, audio rate modulations, using ringmodulator as a waveshaper – your imagination is the limit!


Features

  • Full analogue design
  • Vacuum tube based VCA – two miniature pentodes for better gain reduction
  • Two unconventional CV controls – CVs are not mixed, but they control  different grid voltages of the tubes
  • Manual VCA bias control
  • Manual overdrive
  • Input corossfader
  • Built-in ringmodulator
  • Direct switch for conventional VCA mode
  • Low power consumption due to miniature vacuum tubes



Technical specifications:

Audio Input level 10Vptp
CV input level (full swing) -10V - +10V
Panel width 14HP
Module depth 36mm
Power consumption 48mA@+12V, 69mA@-12V
